| Model specifications | EHXT10 | EHXT40 | EHXT68 | EHXT70 | ENXT70 | EHPXT70 | QME70 |
| Design pressure(MPa) | 14.7 | ||||||
| Working temperature range(℃) | 0-50℃ | ||||||
| Specification of fire extinguishing agent bottle group(L) | 10 | 40 | 68 | 70 | |||
| Working pressure(MPa) | 5.7 | ||||||
| Filling amount of fire extinguishing agent(Kg) | ≤42 | ||||||
| Filling rate(Kg/L) | ≤0.67 | ||||||
| Drive gas source | Nitrogen | ||||||
| Drive air source pressure(MPa) | 6 | ||||||
| Working power supply(V) | AC220 | ||||||
| Emergency power supply(V) | DC24 | ||||||
| Injection time(S) | ≤60 | ||||||
| System startup mode | Automatic/Manual/Emergency Operation | ||||||
| System classification | Unit independent system, combination allocation system | ||||||
| Application location | Marine | Used for offshore platforms | Land use | ||||
